Compressed Air Foam Portable Unit

System Overview

CAFS Technology (Compressed Air Foam Systems) is self contained Stored – Energy Fire Suppression units which have the added ability to inject compressed air into foam solution to generate powerful misting with foam and air. This type of foam has tighter and denser bubble structure allows the foam to adhere to vertical and horizontal surfaces as well as penetrate Fires deeper before the bubbles are broken down, allowing the latent water to be more effective.

TPFCAF 10

TPFCAF 50

Technical Specifications

Model Number	TPFCAF 10	TPFCAF 50
Filling Capacity	10 L	50 L
Operating Pressure	15 Bar	15 Bar
Temperature	0 – 60 Deg C	0 – 60 Deg C
Flow Rate ( Wet Mode )	24.0 LPM	33.4 LPM
Operating Time ( Wet Mode )	25 Second Appx	90 Second Appx
Minimum Hose Length	2.0 Meter	5.0 Meter
Peso Compressed Air Bottle	2.0 L ( 200 Bar )	4.0 L ( 200 Bar )
Lancing Distance ( Wet Mode )	12-15 Meter	12-15 Meter
Empty Weight ( Appx )	15.0 Kg	55.0 Kg
Extinguishing Agent	AFFF Foam + Water	AFFF Foam + Water
Propellant	Compressed Air	Compressed Air
Fire Rating ( Class A )	43 A*	55 A*
Fire Rating ( Class B )	233 B*	233 B*

* Factory Tested

Why Compressed Air Foam Portable Unit

Easy to operate and highly efficient
Low maintenance and high reliability
Large area coverage
